| Interface |
- Mutual Capacitance: 5.6nF/100m nominal
- Characteristic Impedance: 100 ±15%
- Nominal Velocity of Propagation: 69%
- Conductor Resistance: < 9.38 /100m
- Mutual Capacitance: < 5.6nF/100m
- Resistance Unbalance: 5% Max
- Capacitance Unbalance: 330pF/100m
- Delay Skew: < 45nS
- Conductor Diameter: 0.520mm Nominal, 24AWG
- Insulation Diameter: 1.02mm Nominal
- Insulation Material: HD-PE
- Cable Diameter : 6.5mm Nominal
|
